General Serrated Metal Gasket

Flat Metal Gaskets Standard Sizes

These gaskets are manufactured from cold rolled metal plate. They have concentric grooves
machined accurately. The grooves sometimes cause flaws on the gasket seating face of flange,
and be sure to repair the flaw face when changing gaskets.

Standard sizes are prepared to fit JIS and ANSI pipe
flanges. Other gasket sizes are also available with the foll-
owing standard dimensions.

On flat face, raised face, male-and-female flange at high
pressure and high temperature, valve bonnets, joints of
pressure vessels.

These gaskets are produced from cold rolled metal plate. The effective sealing face of the gasket
is machined and polished to perform a satisfactory function as gasket. These gaskets work better
when they are installed on the flanges and joints that are finished with v-groove or groove having
nubbins on the gasket seating face.

Upon request

On pipe flanges to high pressure and high temperature
steam process line, joints of heat exchanger, autoclave
and valve bonnets.



Standard sizes are prepared to fit JIS and ANSI pipe flanges. Other gasket sizes are also available with the foll- owing standard dimensions.


On flat face, raised face, male-and-female flange at high pressure and high temperature, valve bonnets, joints of pressure vessels.



Upon request


On pipe flanges to high pressure and high temperature steam process line, joints of heat exchanger, autoclave and valve bonnets.
